VS-GT100DA120UF Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: SOT-227-4, miniBLOC
- Description: IGBT MOD 1200V 187A 890W SOT227
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
VS-GT100DA120UF Specifications:
- MfrPart.: VS-GT100DA120UF
- Mfr: Vishay General Semiconductor - Diodes Division
- Description: IGBT MOD 1200V 187A 890W SOT227
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: HEXFRED®
- PartStatus: Active
- IGBTType: Trench
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 187 A
- Power-Max: 890 W
- Vce(on)(Max)@VgeIc: 2.55V @ 15V, 100A
- Current-CollectorCutoff(Max): 100 µA
- InputCapacitance(Cies)@Vce: 6.15 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: SOT-227-4, miniBLOC
- VS-GT100DA120UF Vishay, IGBT MOD 1200V 187A 890W SOT227, Discrete Semiconductor Products~Transistors - IGBTs - Modules
