VS-GB300NH120N Vishay IGBT MOD 1200V 500A INT-A-PAK
VS-GB300NH120N Images
VS-GB300NH120N Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Double INT-A-PAK (3 + 4)
  • Description: IGBT MOD 1200V 500A INT-A-PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
VS-GB300NH120N Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
VS-GB300NH120N Specifications:
  • MfrPart.: VS-GB300NH120N
  • Mfr: Vishay General Semiconductor - Diodes Division
  • Description: IGBT MOD 1200V 500A INT-A-PAK
  • Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • IGBTType: -
  • Configuration: Single
  • Voltage-CollectorEmitterBreakdown(Max): 1200 V
  • Current-Collector(Ic)(Max): 500 A
  • Power-Max: 1645 W
  • Vce(on)(Max)@VgeIc: 2.45V @ 15V, 300A
  • Current-CollectorCutoff(Max): 5 mA
  • InputCapacitance(Cies)@Vce: 21.2 nF @ 25 V
  • Input: Standard
  • NTCThermistor: No
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Chassis Mount
  • Package/Case: Double INT-A-PAK (3 + 4)
  • VS-GB300NH120N Vishay, IGBT MOD 1200V 500A INT-A-PAK, Discrete Semiconductor Products~Transistors - IGBTs - Modules
VS-GB300NH120N, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
