VS-GB100NH120N Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Double INT-A-PAK (3 + 4)
- Description: IGBT MOD 1200V 200A INT-A-PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
VS-GB100NH120N Specifications:
- MfrPart.: VS-GB100NH120N
- Mfr: Vishay General Semiconductor - Diodes Division
- Description: IGBT MOD 1200V 200A INT-A-PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Configuration: Single
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 200 A
- Power-Max: 833 W
- Vce(on)(Max)@VgeIc: 2.35V @ 15V, 100A
- Current-CollectorCutoff(Max): 5 mA
- InputCapacitance(Cies)@Vce: 8.58 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Double INT-A-PAK (3 + 4)
- VS-GB100NH120N Vishay, IGBT MOD 1200V 200A INT-A-PAK, Discrete Semiconductor Products~Transistors - IGBTs - Modules
VS-GB100NH120N, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
