VS-CPV363M4UPBF Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: 19-SIP (13 Leads), IMS-2
- Description: IGBT MODULE 600V 13A 36W IMS-2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
VS-CPV363M4UPBF Specifications:
- MfrPart.: VS-CPV363M4UPBF
- Mfr: Vishay General Semiconductor - Diodes Division
- Description: IGBT MODULE 600V 13A 36W IMS-2
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Configuration: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 13 A
- Power-Max: 36 W
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 6.8A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 1.1 nF @ 30 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: 19-SIP (13 Leads), IMS-2
- VS-CPV363M4UPBF Vishay, IGBT MODULE 600V 13A 36W IMS-2, Discrete Semiconductor Products~Transistors - IGBTs - Modules
VS-CPV363M4UPBF, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
