VOD3120AG Images
- Manufacturer: Vishay
- Category: Isolators~Isolators - Gate Drivers Package/Case: 8-DIP (0.400, 10.16mm)
- Description: OPTOISO IGBT MOSFET DRIVER 2.5A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
VOD3120AG Specifications:
- MfrPart.: VOD3120AG
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISO IGBT MOSFET DRIVER 2.5A
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- Technology: Optical Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5300Vrms
- CommonModeTransientImmunity(Min): 35kV/µs
- PropagationDelaytpLH/tpHL(Max): 500ns, 500ns
- PulseWidthDistortion(Max): 70ns
- Rise/FallTime(Typ): 35ns, 35ns
- Current-OutputHighLow: 2.5A
- Current-PeakOutput: 2.5A
- Voltage-Forward(Vf)(Typ): 1.37V
- Current-DCForward(If)(Max): 20 mA
- Voltage-OutputSupply: 15V ~ 30V
- OperatingTemperature: -40°C ~ 105°C
- MountingType: Through Hole
- Package/Case: 8-DIP (0.400, 10.16mm)
- VOD3120AG Vishay, OPTOISO IGBT MOSFET DRIVER 2.5A, Isolators~Isolators - Gate Drivers
VOD3120AG, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
