TCMT1112 Vishay OPTOISOLATOR 3.75KV TRANS 4SOP
TCMT1112 Images
TCMT1112 Images
  • Manufacturer: Vishay
  • Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-SOIC (0.173, 4.40mm Width)
  • Description: OPTOISOLATOR 3.75KV TRANS 4SOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
TCMT1112 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
TCMT1112 Specifications:
  • MfrPart.: TCMT1112
  • Mfr: Vishay Semiconductor Opto Division
  • Description: OPTOISOLATOR 3.75KV TRANS 4SOP
  • Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
  • Package: Tape & Reel (TR)
  • Series: -
  • PartStatus: Obsolete
  • NumberofChannels: 1
  • Voltage-Isolation: 3750Vrms
  • CurrentTransferRatio(Min): 63% @ 10mA
  • CurrentTransferRatio(Max): 125% @ 10mA
  • TurnOn/TurnOffTime(Typ): 5µs, 3µs
  • Rise/FallTime(Typ): 3µs, 4µs
  • InputType: DC
  • OutputType: Transistor
  • Voltage-Output(Max): 70V
  • Current-Output/Channel: 50mA
  • Voltage-Forward(Vf)(Typ): 1.15V
  • Current-DCForward(If)(Max): 50 mA
  • VceSaturation(Max): 300mV
  • OperatingTemperature: -40°C ~ 110°C
  • MountingType: Surface Mount
  • Package/Case: 4-SOIC (0.173, 4.40mm Width)
  • TCMT1112 Vishay, OPTOISOLATOR 3.75KV TRANS 4SOP, Isolators~Optoisolators - Transistor, Photovoltaic Output
TCMT1112, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
