TCLT1105 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-SOIC (0.295, 7.50mm Width), 5 Leads
- Description: OPTOISO 5KV TRANS W/BASE 6SOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TCLT1105 Specifications:
- MfrPart.: TCLT1105
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISO 5KV TRANS W/BASE 6SOP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 50% @ 5mA
- CurrentTransferRatio(Max): 150% @ 5mA
- TurnOn/TurnOffTime(Typ): 6µs, 5µs
- Rise/FallTime(Typ): 3µs, 4.7µs
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 80V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.25V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 6-SOIC (0.295, 7.50mm Width), 5 Leads
- TCLT1105 Vishay, OPTOISO 5KV TRANS W/BASE 6SOP, Isolators~Optoisolators - Transistor, Photovoltaic Output
TCLT1105, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
