TCLT1001 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-SMD, Gull Wing
- Description: OPTOISOLATOR 5KV TRANS SOP-4L
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TCLT1001 Specifications:
- MfrPart.: TCLT1001
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISOLATOR 5KV TRANS SOP-4L
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 40% @ 10mA
- CurrentTransferRatio(Max): 80% @ 10mA
- TurnOn/TurnOffTime(Typ): 6µs, 5µs
- Rise/FallTime(Typ): 3µs, 4.7µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 70V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.25V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 4-SMD, Gull Wing
- TCLT1001 Vishay, OPTOISOLATOR 5KV TRANS SOP-4L, Isolators~Optoisolators - Transistor, Photovoltaic Output
TCLT1001, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
