TCET1114 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-DIP (0.300, 7.62mm)
- Description: OPTOISOLATOR 5KV TRANS 4DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TCET1114 Specifications:
- MfrPart.: TCET1114
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISOLATOR 5KV TRANS 4DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 160% @ 10mA
- CurrentTransferRatio(Max): 320% @ 10mA
- TurnOn/TurnOffTime(Typ): 6µs, 5µs
- Rise/FallTime(Typ): 3µs, 4.7µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 70V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.25V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -40°C ~ 110°C
- MountingType: Through Hole
- Package/Case: 4-DIP (0.300, 7.62mm)
- TCET1114 Vishay, OPTOISOLATOR 5KV TRANS 4DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
TCET1114, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
