TCED1100 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-DIP (0.300, 7.62mm)
- Description: OPTOISOLATOR 5KV TRANS 4DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TCED1100 Specifications:
- MfrPart.: TCED1100
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISOLATOR 5KV TRANS 4DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 600% @ 1mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): -
- Rise/FallTime(Typ): 300µs, 250µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 35V
- Current-Output/Channel: 80mA
- Voltage-Forward(Vf)(Typ): 1.15V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 1V
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 4-DIP (0.300, 7.62mm)
- TCED1100 Vishay, OPTOISOLATOR 5KV TRANS 4DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
TCED1100, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
