SUP90N15-18P-E3 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 150V 90A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SUP90N15-18P-E3 Specifications:
- MfrPart.: SUP90N15-18P-E3
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 150V 90A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: TrenchFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 90A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 18mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 100 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4180 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 3.75W (Ta), 375W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- SUP90N15-18P-E3 Vishay, MOSFET N-CH 150V 90A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SUP90N15-18P-E3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
