SUD40N02-3M3P-E3 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 20V 24.4A/40A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SUD40N02-3M3P-E3 Specifications:
- MfrPart.: SUD40N02-3M3P-E3
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 20V 24.4A/40A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: TrenchFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 24.4A (Ta), 40A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.3mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 160 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6520 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 3.3W (Ta), 79W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- SUD40N02-3M3P-E3 Vishay, MOSFET N-CH 20V 24.4A/40A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
