SQUN702E-T1_GE3 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: Die
- Description: MOSFET N&P-CH COMMON DRAIN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SQUN702E-T1_GE3 Specifications:
- MfrPart.: SQUN702E-T1_GE3
- Mfr: Vishay Siliconix
- Description: MOSFET N&P-CH COMMON DRAIN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, TrenchFET®
- PartStatus: Active
- FETType: N and P-Channel, Common Drain
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 40V, 200V
- Current-ContinuousDrain(Id)@25°C: 30A (Tc), 20A (Tc)
- RdsOn(Max)@IdVgs: 9.2mOhm @ 9.8A, 10V, 60mOhm @ 5A, 10V, 30mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA, 3.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 23nC, 14nC, 30.2nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 1474pF, 1450pF, 1302pF @ 20V, 100V
- Power-Max: 48W (Tc), 60W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount, Wettable Flank
- Package/Case: Die
- SQUN702E-T1_GE3 Vishay, MOSFET N&P-CH COMMON DRAIN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
SQUN702E-T1_GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
