SQM70060EL_GE3 Vishay MOSFET N-CH 100V 75A D2PAK
SQM70060EL_GE3 Images
SQM70060EL_GE3 Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263 (D²Pak)
  • Description: MOSFET N-CH 100V 75A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SQM70060EL_GE3 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SQM70060EL_GE3 Specifications:
  • MfrPart.: SQM70060EL_GE3
  • Mfr: Vishay Siliconix
  • Description: MOSFET N-CH 100V 75A D2PAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: Automotive, AEC-Q101, TrenchFET®
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 100 V
  • Current-ContinuousDrain(Id)@25°C: 75A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 5.9mOhm @ 30A, 10V
  • Vgs(th)(Max)@Id: 2.5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 100 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 5500 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 166W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: TO-263 (D²Pak)
  • SQM70060EL_GE3 Vishay, MOSFET N-CH 100V 75A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SQM70060EL_GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
