SQJ504EP-T1_GE3 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: PowerPAK® SO-8 Dual
- Description: MOSFET N/P CHAN 40V POWERPAK SO-
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SQJ504EP-T1_GE3 Specifications:
- MfrPart.: SQJ504EP-T1_GE3
- Mfr: Vishay Siliconix
- Description: MOSFET N/P CHAN 40V POWERPAK SO-
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, TrenchFET®
- PartStatus: Active
- FETType: N and P-Channel
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 40V
- Current-ContinuousDrain(Id)@25°C: 30A (Tc)
- RdsOn(Max)@IdVgs: 7.5mOhm @ 8A, 10V, 17mOhm @ 8A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 30nC @ 10V, 85nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 1900pF @ 25V, 4600pF @ 25V
- Power-Max: 34W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: PowerPAK® SO-8 Dual
- SQJ504EP-T1_GE3 Vishay, MOSFET N/P CHAN 40V POWERPAK SO-, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
SQJ504EP-T1_GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
