SQD45N05-20L-GE3 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 50V 50A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SQD45N05-20L-GE3 Specifications:
- MfrPart.: SQD45N05-20L-GE3
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 50V 50A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: TrenchFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 50 V
- Current-ContinuousDrain(Id)@25°C: 50A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 18mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 43 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1800 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 75W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- SQD45N05-20L-GE3 Vishay, MOSFET N-CH 50V 50A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SQD45N05-20L-GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
