SI3805DV-T1-E3 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-TSOP
- Description: MOSFET P-CH 20V 3.3A 6TSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SI3805DV-T1-E3 Specifications:
- MfrPart.: SI3805DV-T1-E3
- Mfr: Vishay Siliconix
- Description: MOSFET P-CH 20V 3.3A 6TSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: LITTLE FOOT®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.3A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 10V
- RdsOn(Max)@IdVgs: 84mOhm @ 3A, 10V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 12 nC @ 10 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 330 pF @ 10 V
- FETFeature: Schottky Diode (Isolated)
- PowerDissipation(Max): 1.1W (Ta), 1.4W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-TSOP
- SI3805DV-T1-E3 Vishay, MOSFET P-CH 20V 3.3A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SI3805DV-T1-E3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
