SI1563EDH-T1-E3 Vishay MOSFET N/P-CH 20V 1.13A SC70-6
SI1563EDH-T1-E3 Images
SI1563EDH-T1-E3 Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 6-TSSOP, SC-88, SOT-363
  • Description: MOSFET N/P-CH 20V 1.13A SC70-6
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SI1563EDH-T1-E3 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SI1563EDH-T1-E3 Specifications:
  • MfrPart.: SI1563EDH-T1-E3
  • Mfr: Vishay Siliconix
  • Description: MOSFET N/P-CH 20V 1.13A SC70-6
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: TrenchFET®
  • PartStatus: Obsolete
  • FETType: N and P-Channel
  • FETFeature: Logic Level Gate
  • DraintoSourceVoltage(Vdss): 20V
  • Current-ContinuousDrain(Id)@25°C: 1.13A, 880mA
  • RdsOn(Max)@IdVgs: 280mOhm @ 1.13A, 4.5V
  • Vgs(th)(Max)@Id: 1V @ 100µA
  • GateCharge(Qg)(Max)@Vgs: 1nC @ 4.5V
  • InputCapacitance(Ciss)(Max)@Vds: -
  • Power-Max: 570mW
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 6-TSSOP, SC-88, SOT-363
  • SI1563EDH-T1-E3 Vishay, MOSFET N/P-CH 20V 1.13A SC70-6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
SI1563EDH-T1-E3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
