SFH690ABT Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-SMD, Gull Wing
- Description: OPTOISOLATOR 3.75KV TRANS 4-SOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SFH690ABT Specifications:
- MfrPart.: SFH690ABT
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISOLATOR 3.75KV TRANS 4-SOP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 3750Vrms
- CurrentTransferRatio(Min): 50% @ 5mA
- CurrentTransferRatio(Max): 300% @ 5mA
- TurnOn/TurnOffTime(Typ): 5µs, 3µs
- Rise/FallTime(Typ): 3µs, 4µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 70V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.15V
- Current-DCForward(If)(Max): 50 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 4-SMD, Gull Wing
- SFH690ABT Vishay, OPTOISOLATOR 3.75KV TRANS 4-SOP, Isolators~Optoisolators - Transistor, Photovoltaic Output
SFH690ABT, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
