SFH6701-X009 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Logic Output Package/Case: 8-SMD, Gull Wing
- Description: OPTOISO 5.3KV PUSH PULL 8SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SFH6701-X009 Specifications:
- MfrPart.: SFH6701-X009
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISO 5.3KV PUSH PULL 8SMD
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Inputs-Side1/Side2: 1/0
- Voltage-Isolation: 5300Vrms
- CommonModeTransientImmunity(Min): 1kV/µs
- InputType: DC
- OutputType: Push-Pull, Totem Pole
- Current-Output/Channel: 25 mA
- DataRate: 5MBd
- PropagationDelaytpLH/tpHL(Max): 300ns, 300ns
- Rise/FallTime(Typ): 40ns, 10ns
- Voltage-Forward(Vf)(Typ): 1.6V
- Current-DCForward(If)(Max): 10mA
- Voltage-Supply: 4.5V ~ 15V
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 8-SMD, Gull Wing
- SFH6701-X009 Vishay, OPTOISO 5.3KV PUSH PULL 8SMD, Isolators~Optoisolators - Logic Output
SFH6701-X009, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
