SFH6700-X009 Vishay OPTOISO 5.3KV TRI-STATE 8SMD
SFH6700-X009 Images
SFH6700-X009 Images
  • Manufacturer: Vishay
  • Category: Isolators~Optoisolators - Logic Output Package/Case: 8-SMD, Gull Wing
  • Description: OPTOISO 5.3KV TRI-STATE 8SMD
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SFH6700-X009 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SFH6700-X009 Specifications:
  • MfrPart.: SFH6700-X009
  • Mfr: Vishay Semiconductor Opto Division
  • Description: OPTOISO 5.3KV TRI-STATE 8SMD
  • Product Category: Isolators~Optoisolators - Logic Output
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • NumberofChannels: 1
  • Inputs-Side1/Side2: 1/0
  • Voltage-Isolation: 5300Vrms
  • CommonModeTransientImmunity(Min): 1kV/µs
  • InputType: DC
  • OutputType: Tri-State
  • Current-Output/Channel: 25 mA
  • DataRate: 5MBd
  • PropagationDelaytpLH/tpHL(Max): 300ns, 300ns
  • Rise/FallTime(Typ): 40ns, 10ns
  • Voltage-Forward(Vf)(Typ): 1.6V
  • Current-DCForward(If)(Max): 10mA
  • Voltage-Supply: 4.5V ~ 15V
  • OperatingTemperature: -40°C ~ 85°C
  • MountingType: Surface Mount
  • Package/Case: 8-SMD, Gull Wing
  • SFH6700-X009 Vishay, OPTOISO 5.3KV TRI-STATE 8SMD, Isolators~Optoisolators - Logic Output
SFH6700-X009, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
