MOC8104 Vishay OPTOISOLATOR 5.3KV TRANS 6-DIP
MOC8104 Images
MOC8104 Images
  • Manufacturer: Vishay
  • Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.300, 7.62mm)
  • Description: OPTOISOLATOR 5.3KV TRANS 6-DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MOC8104 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MOC8104 Specifications:
  • MfrPart.: MOC8104
  • Mfr: Vishay Semiconductor Opto Division
  • Description: OPTOISOLATOR 5.3KV TRANS 6-DIP
  • Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • NumberofChannels: 1
  • Voltage-Isolation: 5300Vrms
  • CurrentTransferRatio(Min): 160% @ 10mA
  • CurrentTransferRatio(Max): 256% @ 10mA
  • TurnOn/TurnOffTime(Typ): 3µs, 2.3µs
  • Rise/FallTime(Typ): 2µs, 2µs
  • InputType: DC
  • OutputType: Transistor
  • Voltage-Output(Max): 30V
  • Current-Output/Channel: 50mA
  • Voltage-Forward(Vf)(Typ): 1.25V
  • Current-DCForward(If)(Max): 60 mA
  • VceSaturation(Max): 400mV
  • OperatingTemperature: -55°C ~ 100°C
  • MountingType: Through Hole
  • Package/Case: 6-DIP (0.300, 7.62mm)
  • MOC8104 Vishay, OPTOISOLATOR 5.3KV TRANS 6-DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
MOC8104, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
