LL101C-13 Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-213AC, MINI-MELF, SOD-80
- Description: DIODE SCHOTTKY 40V 30MA SOD80
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LL101C-13 Specifications:
- Manufacturer Product Number: LL101C-13
- Mfr: Vishay General Semiconductor - Diodes Division
- Detailed Description: DIODE SCHOTTKY 40V 30MA SOD80
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io): 30mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 390 mV @ 1 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 1 ns
- Current - Reverse Leakage @ Vr: 200 nA @ 30 V
- Capacitance @ Vr, F: 2.2pF @ 0V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: DO-213AC, MINI-MELF, SOD-80
- Operating Temperature - Junction: 125°C (Max)
- LL101C-13 Vishay, DIODE SCHOTTKY 40V 30MA SOD80, Discrete Semiconductor Products~Diodes - Rectifiers - Single
