IRLZ14PBF Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 60V 10A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLZ14PBF Specifications:
- MfrPart.: IRLZ14PBF
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 60V 10A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 10A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 5V
- RdsOn(Max)@IdVgs: 200mOhm @ 6A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 8.4 nC @ 5 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 400 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 43W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- IRLZ14PBF Vishay, MOSFET N-CH 60V 10A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLZ14PBF, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
