IRFU9120 Vishay MOSFET P-CH 100V 5.6A TO251AA
IRFU9120 Images
IRFU9120 Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-251AA
  • Description: MOSFET P-CH 100V 5.6A TO251AA
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
IRFU9120 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
IRFU9120 Specifications:
  • MfrPart.: IRFU9120
  • Mfr: Vishay Siliconix
  • Description: MOSFET P-CH 100V 5.6A TO251AA
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • FETType: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 100 V
  • Current-ContinuousDrain(Id)@25°C: 5.6A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 600mOhm @ 3.4A, 10V
  • Vgs(th)(Max)@Id: 4V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 18 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 390 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 2.5W (Ta), 42W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • SupplierDevicePackage: TO-251AA
  • IRFU9120 Vishay, MOSFET P-CH 100V 5.6A TO251AA, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
