IRFR120TRR Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D-Pak
- Description: MOSFET N-CH 100V 7.7A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRFR120TRR Specifications:
- MfrPart.: IRFR120TRR
- Mfr: Vishay Siliconix
- Description: MOSFET N-CH 100V 7.7A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 7.7A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 270mOhm @ 4.6A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 16 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 360 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 42W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D-Pak
- IRFR120TRR Vishay, MOSFET N-CH 100V 7.7A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
