IRFI9520N Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-3
- Description: MOSFET P-CH 100V 5.5A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRFI9520N Specifications:
- MfrPart.: IRFI9520N
- Mfr: Vishay Siliconix
- Description: MOSFET P-CH 100V 5.5A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 5.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 480mOhm @ 4A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 27 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 350 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 30W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-3
- IRFI9520N Vishay, MOSFET P-CH 100V 5.5A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRFI9520N, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
