IRF9540STRLPBF Images
- Manufacturer: Vishay
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK (TO-263)
- Description: MOSFET P-CH 100V 19A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF9540STRLPBF Specifications:
- MfrPart.: IRF9540STRLPBF
- Mfr: Vishay Siliconix
- Description: MOSFET P-CH 100V 19A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 19A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 200mOhm @ 11A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 61 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1400 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.7W (Ta), 150W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK (TO-263)
- IRF9540STRLPBF Vishay, MOSFET P-CH 100V 19A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF9540STRLPBF, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
