IRF9520SPBF Vishay MOSFET P-CH 100V 6.8A D2PAK
IRF9520SPBF Images
IRF9520SPBF Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
  • Description: MOSFET P-CH 100V 6.8A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
IRF9520SPBF Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
IRF9520SPBF Specifications:
  • MfrPart.: IRF9520SPBF
  • Mfr: Vishay Siliconix
  • Description: MOSFET P-CH 100V 6.8A D2PAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • FETType: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 100 V
  • Current-ContinuousDrain(Id)@25°C: 6.8A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 600mOhm @ 4.1A, 10V
  • Vgs(th)(Max)@Id: 4V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 18 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 390 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 3.7W (Ta), 60W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: D2PAK
  • IRF9520SPBF Vishay, MOSFET P-CH 100V 6.8A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF9520SPBF, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
