IRF820AS Vishay MOSFET N-CH 500V 2.5A D2PAK
IRF820AS Images
IRF820AS Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK (TO-263)
  • Description: MOSFET N-CH 500V 2.5A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
IRF820AS Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
IRF820AS Specifications:
  • MfrPart.: IRF820AS
  • Mfr: Vishay Siliconix
  • Description: MOSFET N-CH 500V 2.5A D2PAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 500 V
  • Current-ContinuousDrain(Id)@25°C: 2.5A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 3Ohm @ 1.5A, 10V
  • Vgs(th)(Max)@Id: 4.5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 17 nC @ 10 V
  • Vgs(Max): ±30V
  • InputCapacitance(Ciss)(Max)@Vds: 340 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 50W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: D²PAK (TO-263)
  • IRF820AS Vishay, MOSFET N-CH 500V 2.5A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF820AS, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
