IMS05WDEB220J40 Images
- Manufacturer: Vishay
- Category: Inductors, Coils, Chokes~Fixed Inductors Package/Case: Axial
- Description: FIXED IND 22UH 590MA 950 MOHM TH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IMS05WDEB220J40 Specifications:
- MfrPart.: IMS05WDEB220J40
- Mfr: Vishay Dale
- Description: FIXED IND 22UH 590MA 950 MOHM TH
- Product Category: Inductors, Coils, Chokes~Fixed Inductors
- Package: -
- Series: IMS-5WD-40
- PartStatus: Obsolete
- Type: -
- Material-Core: Ferrite
- Inductance: 22 µH
- Tolerance: ±10%
- CurrentRating(Amps): 590 mA
- Current-Saturation(Isat): 220mA
- Shielding: Shielded
- DCResistance(DCR): 950mOhm Max
- Q@Freq: 47 @ 2.5MHz
- Frequency-SelfResonant: 38MHz
- Ratings: -
- OperatingTemperature: -55°C ~ 125°C
- InductanceFrequency-Test: 2.5 MHz
- Features: -
- MountingType: Through Hole
- Package/Case: Axial
- SupplierDevicePackage: -
- Size/Dimension: 0.164 Dia x 0.450 L (4.17mm x 11.43mm)
- IMS05WDEB220J40 Vishay, FIXED IND 22UH 590MA 950 MOHM TH, Inductors, Coils, Chokes~Fixed Inductors
IMS05WDEB220J40, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
