IMS05SH822K Images
- Manufacturer: Vishay
- Category: Inductors, Coils, Chokes~Fixed Inductors Package/Case: Axial
- Description: FIXED IND 8.2MH 26MA 119 OHM TH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IMS05SH822K Specifications:
- MfrPart.: IMS05SH822K
- Mfr: Vishay Dale
- Description: FIXED IND 8.2MH 26MA 119 OHM TH
- Product Category: Inductors, Coils, Chokes~Fixed Inductors
- Package: -
- Series: IMS-5
- PartStatus: Obsolete
- Type: Molded
- Material-Core: Ferrite
- Inductance: 8.2 mH
- Tolerance: ±10%
- CurrentRating(Amps): 26 mA
- Current-Saturation(Isat): 15mA
- Shielding: Shielded
- DCResistance(DCR): 119Ohm Max
- Q@Freq: 40 @ 250kHz
- Frequency-SelfResonant: 540kHz
- Ratings: -
- OperatingTemperature: -55°C ~ 105°C
- InductanceFrequency-Test: 250 kHz
- Features: -
- MountingType: Through Hole
- Package/Case: Axial
- SupplierDevicePackage: -
- Size/Dimension: 0.162 Dia x 0.410 L (4.11mm x 10.41mm)
- IMS05SH822K Vishay, FIXED IND 8.2MH 26MA 119 OHM TH, Inductors, Coils, Chokes~Fixed Inductors
IMS05SH822K, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
