IMS05SH150K Vishay FIXED IND 15UH 315MA 800 MOHM TH
IMS05SH150K Images
IMS05SH150K Images
  • Manufacturer: Vishay
  • Category: Inductors, Coils, Chokes~Fixed Inductors Package/Case: Axial
  • Description: FIXED IND 15UH 315MA 800 MOHM TH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
IMS05SH150K Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
IMS05SH150K Specifications:
  • MfrPart.: IMS05SH150K
  • Mfr: Vishay Dale
  • Description: FIXED IND 15UH 315MA 800 MOHM TH
  • Product Category: Inductors, Coils, Chokes~Fixed Inductors
  • Package: -
  • Series: IMS-5
  • PartStatus: Obsolete
  • Type: Molded
  • Material-Core: Ferrite
  • Inductance: 15 µH
  • Tolerance: ±10%
  • CurrentRating(Amps): 315 mA
  • Current-Saturation(Isat): 250mA
  • Shielding: Shielded
  • DCResistance(DCR): 800mOhm Max
  • Q@Freq: 45 @ 2.5MHz
  • Frequency-SelfResonant: 49MHz
  • Ratings: -
  • OperatingTemperature: -55°C ~ 105°C
  • InductanceFrequency-Test: 2.5 MHz
  • Features: -
  • MountingType: Through Hole
  • Package/Case: Axial
  • SupplierDevicePackage: -
  • Size/Dimension: 0.162 Dia x 0.410 L (4.11mm x 10.41mm)
  • IMS05SH150K Vishay, FIXED IND 15UH 315MA 800 MOHM TH, Inductors, Coils, Chokes~Fixed Inductors
IMS05SH150K, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
