IM04SHR56K Images
- Manufacturer: Vishay
- Category: Inductors, Coils, Chokes~Fixed Inductors Package/Case: Axial
- Description: FIXED IND 560NH 1.15A 135MOHM TH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IM04SHR56K Specifications:
- MfrPart.: IM04SHR56K
- Mfr: Vishay Dale
- Description: FIXED IND 560NH 1.15A 135MOHM TH
- Product Category: Inductors, Coils, Chokes~Fixed Inductors
- Package: -
- Series: IM
- PartStatus: Obsolete
- Type: Molded
- Material-Core: Phenolic
- Inductance: 560 nH
- Tolerance: ±10%
- CurrentRating(Amps): 1.15 A
- Current-Saturation(Isat): -
- Shielding: Unshielded
- DCResistance(DCR): 135mOhm Max
- Q@Freq: 50 @ 25MHz
- Frequency-SelfResonant: 280MHz
- Ratings: -
- OperatingTemperature: -55°C ~ 105°C
- InductanceFrequency-Test: 25 MHz
- Features: -
- MountingType: Through Hole
- Package/Case: Axial
- SupplierDevicePackage: -
- Size/Dimension: 0.155 Dia x 0.375 L (3.94mm x 9.53mm)
- IM04SHR56K Vishay, FIXED IND 560NH 1.15A 135MOHM TH, Inductors, Coils, Chokes~Fixed Inductors
IM04SHR56K, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
