H11D1 Images
- Manufacturer: Vishay
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.300, 7.62mm)
- Description: OPTOISO 5.3KV TRANS W/BASE 6DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
H11D1 Specifications:
- MfrPart.: H11D1
- Mfr: Vishay Semiconductor Opto Division
- Description: OPTOISO 5.3KV TRANS W/BASE 6DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5300Vrms
- CurrentTransferRatio(Min): 20% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 2.5µs, 5.5µs
- Rise/FallTime(Typ): 5µs, 6µs
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 300V
- Current-Output/Channel: 100mA
- Voltage-Forward(Vf)(Typ): 1.1V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 400mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 6-DIP (0.300, 7.62mm)
- H11D1 Vishay, OPTOISO 5.3KV TRANS W/BASE 6DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
H11D1, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
