H11AA1-X001 Vishay OPTOISO 5.3KV TRANS W/BASE 6DIP
H11AA1-X001 Images
H11AA1-X001 Images
  • Manufacturer: Vishay
  • Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.300, 7.62mm)
  • Description: OPTOISO 5.3KV TRANS W/BASE 6DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
H11AA1-X001 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
H11AA1-X001 Specifications:
  • MfrPart.: H11AA1-X001
  • Mfr: Vishay Semiconductor Opto Division
  • Description: OPTOISO 5.3KV TRANS W/BASE 6DIP
  • Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • NumberofChannels: 1
  • Voltage-Isolation: 5300Vrms
  • CurrentTransferRatio(Min): 20% @ 10mA
  • CurrentTransferRatio(Max): -
  • TurnOn/TurnOffTime(Typ): -
  • Rise/FallTime(Typ): -
  • InputType: AC, DC
  • OutputType: Transistor with Base
  • Voltage-Output(Max): 30V
  • Current-Output/Channel: -
  • Voltage-Forward(Vf)(Typ): 1.2V
  • Current-DCForward(If)(Max): 60 mA
  • VceSaturation(Max): 400mV
  • OperatingTemperature: -55°C ~ 100°C
  • MountingType: Through Hole
  • Package/Case: 6-DIP (0.300, 7.62mm)
  • H11AA1-X001 Vishay, OPTOISO 5.3KV TRANS W/BASE 6DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
H11AA1-X001, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
