DG642DJ Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC VIDEO SWITCH SPDT 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG642DJ Specifications:
- MfrPart.: DG642DJ
- Mfr: Vishay Siliconix
- Description: IC VIDEO SWITCH SPDT 8DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 1
- On-StateResistance(Max): 8Ohm
- Channel-to-ChannelMatching(ΔRon): 500mOhm
- Voltage-SupplySingle(V+): 3V ~ 15V
- Voltage-SupplyDual(V±): ±3V ~ 15V
- SwitchTime(TonToff)(Max): 100ns, 60ns
- -3dbBandwidth: 500MHz
- ChargeInjection: 40pC
- ChannelCapacitance(CS(off)CD(off)): 20pF, 20pF
- Current-Leakage(IS(off))(Max): 10nA
- Crosstalk: -85dB @ 5MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- DG642DJ Vishay, IC VIDEO SWITCH SPDT 8DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG642DJ, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
