DG506BEN-T1-GE3 Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 28-LCC (J-Lead)
- Description: IC MUX ANALOG DUAL 16/8CH 28PLCC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG506BEN-T1-GE3 Specifications:
- MfrPart.: DG506BEN-T1-GE3
- Mfr: Vishay Siliconix
- Description: IC MUX ANALOG DUAL 16/8CH 28PLCC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- SwitchCircuit: -
- Multiplexer/DemultiplexerCircuit: 16:1
- NumberofCircuits: 1
- On-StateResistance(Max): 300Ohm
- Channel-to-ChannelMatching(ΔRon): 10Ohm
- Voltage-SupplySingle(V+): 12V
- Voltage-SupplyDual(V±): ±5V ~ 20V
- SwitchTime(TonToff)(Max): 250ns, 200ns
- -3dbBandwidth: 114MHz
- ChargeInjection: 1pC
- ChannelCapacitance(CS(off)CD(off)): 3pF, 13pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -85dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 28-LCC (J-Lead)
- DG506BEN-T1-GE3 Vishay, IC MUX ANALOG DUAL 16/8CH 28PLCC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG506BEN-T1-GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
