DG442BDN-T1-E4 Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-VQFN Exposed Pad
- Description: IC SWITCH QUAD SPST 16QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG442BDN-T1-E4 Specifications:
- MfrPart.: DG442BDN-T1-E4
- Mfr: Vishay Siliconix
- Description: IC SWITCH QUAD SPST 16QFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 80Ohm
- Channel-to-ChannelMatching(ΔRon): 2Ohm
- Voltage-SupplySingle(V+): 12V
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 220ns, 120ns
- -3dbBandwidth: -
- ChargeInjection: -1pC
- ChannelCapacitance(CS(off)CD(off)): 4pF, 4pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -95dB @ 100kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-VQFN Exposed Pad
- DG442BDN-T1-E4 Vishay, IC SWITCH QUAD SPST 16QFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG442BDN-T1-E4, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
