DG419BAK Vishay IC ANALOG SWITCH CMOS 8DIP
DG419BAK Images
DG419BAK Images
  • Manufacturer: Vishay
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-CDIP (0.300, 7.62mm)
  • Description: IC ANALOG SWITCH CMOS 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG419BAK Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG419BAK Specifications:
  • MfrPart.: DG419BAK
  • Mfr: Vishay Siliconix
  • Description: IC ANALOG SWITCH CMOS 8DIP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 25Ohm
  • Channel-to-ChannelMatching(ΔRon): -
  • Voltage-SupplySingle(V+): 12V
  • Voltage-SupplyDual(V±): ±15V
  • SwitchTime(TonToff)(Max): 89ns, 80ns
  • -3dbBandwidth: -
  • ChargeInjection: 38pC
  • ChannelCapacitance(CS(off)CD(off)): 12pF, 12pF
  • Current-Leakage(IS(off))(Max): 250pA
  • Crosstalk: -88dB @ 1MHz
  • OperatingTemperature: -55°C ~ 125°C (TA)
  • MountingType: Through Hole
  • Package/Case: 8-CDIP (0.300, 7.62mm)
  • DG419BAK Vishay, IC ANALOG SWITCH CMOS 8DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG419BAK, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
