DG409LEDY-GE3 Vishay IC MUX CMOS DUAL 4CH 16-SOIC
DG409LEDY-GE3 Images
DG409LEDY-GE3 Images
  • Manufacturer: Vishay
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
  • Description: IC MUX CMOS DUAL 4CH 16-SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG409LEDY-GE3 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG409LEDY-GE3 Specifications:
  • MfrPart.: DG409LEDY-GE3
  • Mfr: Vishay Siliconix
  • Description: IC MUX CMOS DUAL 4CH 16-SOIC
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 23Ohm
  • Channel-to-ChannelMatching(ΔRon): 1Ohm
  • Voltage-SupplySingle(V+): 3V ~ 16V
  • Voltage-SupplyDual(V±): ±3.3V ~ 8V
  • SwitchTime(TonToff)(Max): 72ns, 47ns
  • -3dbBandwidth: -
  • ChargeInjection: -10pC
  • ChannelCapacitance(CS(off)CD(off)): 5.5pF, 13.5pF
  • Current-Leakage(IS(off))(Max): 1nA
  • Crosstalk: -109dB @ 100kHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-SOIC (0.154, 3.90mm Width)
  • DG409LEDY-GE3 Vishay, IC MUX CMOS DUAL 4CH 16-SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG409LEDY-GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
