DG309BDQ-E3 Vishay IC SWITCH QUAD CMOS 16TSSOP
DG309BDQ-E3 Images
DG309BDQ-E3 Images
  • Manufacturer: Vishay
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • Description: IC SWITCH QUAD CMOS 16TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
DG309BDQ-E3 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
DG309BDQ-E3 Specifications:
  • MfrPart.: DG309BDQ-E3
  • Mfr: Vishay Siliconix
  • Description: IC SWITCH QUAD CMOS 16TSSOP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NC
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 85Ohm
  • Channel-to-ChannelMatching(ΔRon): 1.7Ohm
  • Voltage-SupplySingle(V+): 4V ~ 44V
  • Voltage-SupplyDual(V±): ±4V ~ 22V
  • SwitchTime(TonToff)(Max): 200ns, 150ns
  • -3dbBandwidth: -
  • ChargeInjection: 1pC
  • ChannelCapacitance(CS(off)CD(off)): 5pF, 5pF
  • Current-Leakage(IS(off))(Max): 500pA
  • Crosstalk: -95dB @ 100kHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • DG309BDQ-E3 Vishay, IC SWITCH QUAD CMOS 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG309BDQ-E3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
