DG300BDJ-E3 Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-DIP (0.300, 7.62mm)
- Description: IC SWITCH CMOS 14DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG300BDJ-E3 Specifications:
- MfrPart.: DG300BDJ-E3
- Mfr: Vishay Siliconix
- Description: IC SWITCH CMOS 14DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 50Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 150ns, 130ns (Typ)
- -3dbBandwidth: -
- ChargeInjection: 8pC
- ChannelCapacitance(CS(off)CD(off)): 14pF, 14pF
- Current-Leakage(IS(off))(Max): 5nA
- Crosstalk: -74dB @ 500kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 14-DIP (0.300, 7.62mm)
- DG300BDJ-E3 Vishay, IC SWITCH CMOS 14DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG300BDJ-E3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
