DG2749DN-T1-E4 Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-UFQFN
- Description: IC SWITCH LV DUAL SPST 8MINIQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG2749DN-T1-E4 Specifications:
- MfrPart.: DG2749DN-T1-E4
- Mfr: Vishay Siliconix
- Description: IC SWITCH LV DUAL SPST 8MINIQFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 600mOhm
- Channel-to-ChannelMatching(ΔRon): 30mOhm (Max)
- Voltage-SupplySingle(V+): 1.6V ~ 4.3V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 25ns, 25ns
- -3dbBandwidth: 93MHz
- ChargeInjection: 10pC
- ChannelCapacitance(CS(off)CD(off)): 75pF, 55pF
- Current-Leakage(IS(off))(Max): 2nA
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 8-UFQFN
- DG2749DN-T1-E4 Vishay, IC SWITCH LV DUAL SPST 8MINIQFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG2749DN-T1-E4, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
