DG271AK Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD SPST/CMOS 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG271AK Specifications:
- MfrPart.: DG271AK
- Mfr: Vishay Siliconix
- Description: IC SWITCH QUAD SPST/CMOS 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 50Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 65ns, 65ns
- -3dbBandwidth: -
- ChargeInjection: -5pC
- ChannelCapacitance(CS(off)CD(off)): 8pF, 8pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -100dB @ 100kHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-CDIP (0.300, 7.62mm)
- DG271AK Vishay, IC SWITCH QUAD SPST/CMOS 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG271AK, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
