DG2707DN-T1-E4 Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-WFQFN
- Description: IC MUX/SW ANLG LV CMOS 16MINIQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG2707DN-T1-E4 Specifications:
- MfrPart.: DG2707DN-T1-E4
- Mfr: Vishay Siliconix
- Description: IC MUX/SW ANLG LV CMOS 16MINIQFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 5.5Ohm
- Channel-to-ChannelMatching(ΔRon): 300mOhm
- Voltage-SupplySingle(V+): 1.65V ~ 4.3V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 45ns, 35ns
- -3dbBandwidth: 120MHz
- ChargeInjection: -14pC
- ChannelCapacitance(CS(off)CD(off)): 16pF, 42pF
- Current-Leakage(IS(off))(Max): 5nA
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-WFQFN
- DG2707DN-T1-E4 Vishay, IC MUX/SW ANLG LV CMOS 16MINIQFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG2707DN-T1-E4, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
