DG1411EQ-T1-GE3 Images
- Manufacturer: Vishay
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC SWITCH QUAD SPST 16-TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DG1411EQ-T1-GE3 Specifications:
- MfrPart.: DG1411EQ-T1-GE3
- Mfr: Vishay Siliconix
- Description: IC SWITCH QUAD SPST 16-TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 1.8Ohm
- Channel-to-ChannelMatching(ΔRon): 80mOhm
- Voltage-SupplySingle(V+): 4.5V ~ 24V
- Voltage-SupplyDual(V±): ±4.5V ~ 15V
- SwitchTime(TonToff)(Max): 150ns, 120ns
- -3dbBandwidth: 210MHz
- ChargeInjection: -20pC
- ChannelCapacitance(CS(off)CD(off)): 11pF, 24pF
- Current-Leakage(IS(off))(Max): 550pA
- Crosstalk: -100dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- DG1411EQ-T1-GE3 Vishay, IC SWITCH QUAD SPST 16-TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
DG1411EQ-T1-GE3, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
