12TTS08S Vishay SCR 800V 12.5A D2PAK
12TTS08S Images
12TTS08S Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Description: SCR 800V 12.5A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
12TTS08S Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
12TTS08S Specifications:
  • MfrPart.: 12TTS08S
  • Mfr: Vishay General Semiconductor - Diodes Division
  • Description: SCR 800V 12.5A D2PAK
  • Product Category: Discrete Semiconductor Products~Thyristors - SCRs
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • Voltage-OffState: 800 V
  • Voltage-GateTrigger(Vgt)(Max): 1 V
  • Current-GateTrigger(Igt)(Max): 15 mA
  • Voltage-OnState(Vtm)(Max): 1.2 V
  • Current-OnState(It(AV))(Max): 8 A
  • Current-OnState(It(RMS))(Max): 12.5 A
  • Current-Hold(Ih)(Max): 30 mA
  • Current-OffState(Max): 500 µA
  • Current-NonRepSurge5060Hz(Itsm): 140A @ 50Hz
  • SCRType: Standard Recovery
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • 12TTS08S Vishay, SCR 800V 12.5A D2PAK, Discrete Semiconductor Products~Thyristors - SCRs
12TTS08S, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
