12CWQ10FN Vishay DIODE ARRAY SCHOTTKY 100V DPAK
12CWQ10FN Images
12CWQ10FN Images
  • Manufacturer: Vishay
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Description: DIODE ARRAY SCHOTTKY 100V DPAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
12CWQ10FN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
12CWQ10FN Specifications:
  • Mfr Part: 12CWQ10FN
  • Mfr: Vishay General Semiconductor - Diodes Division
  • Description: DIODE ARRAY SCHOTTKY 100V DPAK
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tube
  • Series: -
  • Part Status: Obsolete
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 100 V
  • Current - Average Rectified (Io) (per Diode): 6A
  • Voltage - Forward (Vf) (Max) @ If: 800 mV @ 6 A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 1 mA @ 100 V
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • 12CWQ10FN Vishay, DIODE ARRAY SCHOTTKY 100V DPAK, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
12CWQ10FN, Vishay authentic parts in stock from Vishay authorized distributors, order today, can ship immediately.
